Specification
| Model No. | PTB-16E-1 | Color | Grey,Black,White. |
| Capacity | 16ports Waterproof Mini SC APC+24F Fusion Splice | Protection Level | IP65 Indoor/Outdoor |
| Material | PC+ABS, ABS | Flame retardant performance | Non-flame retardant |
| Dimension(L*W*D,) | 241x208x117mm | Suitable Splitter | 1:8 or 2:8 or 1:16 Blockless PLC Splitter |
| Input Cable OD | 1mid span(Φ16mm Max), | Output Adapter | 18x Mini SCAPC waterproof adapters<0.2dB |
| Installation Method | Wall&Pole mounted | Insertion loss | ≤0.2dB（1310nm & 1550nm) |
| Model No. | PTB-16E-2 | Color | Grey,Black,White. |
| Capacity | 16ports Waterproof Tyco SC APC+24F Fusion Splice | Protection Level | IP65 Indoor/Outdoor |
| Material | PC+ABS, ABS | Flame retardant performance | Non-flame retardant |
| Dimension(L*W*D,) | 299x213x117mm | Suitable Splitter | 1:8 or 2:8 or 1:16 Blockless PLC Splitter |
| Input Cable OD | 1mid span(Φ16mm Max), | Output Adapter | 18x Mini SCAPC waterproof adapters<0.2dB |
| Installation Method | Wall&Pole mounted | Insertion loss | ≤0.2dB（1310nm & 1550nm) |
1.Wall-mounted installation
Drill 4 holes into the wall based on the size in table 1, place the expansion bolt Φ7.5*40, place the box to match up the holes and use bolt to fasten.
Pole-mounted installation
Fix 1 set of the pole ring to the telecom pole
Environmental requirement
Working temperature：-40℃～+85℃
Relative humidity：≤85%（+30℃）
Atmospheric pressure：70KPa～106Kpa
Main technical datasheet:
Insertion loss：≤0.2dB
UPC return loss：≥50dB
APC return loss：≥60dB
Thunder-proof technical datasheet
The insulation resistance between the grounding device and the metal parts of the box is no less than 2 x 104 MΩ/500V（DC）；IR≥2×104 MΩ/500V, The voltage resistance between the grounding device, and the box and its metal
parts is no less than 3000V（DC）/min, no puncture，no flashover；U≥3000V
