FTTH 16cores Fiber Distribution Box -(FTB-16A-1)

Fiber distribution box(FDB) is widely used in FTTH access network, telecommunication network, CATV network, Data communication network and local area network(LAN)

Product feature

Overview:

Starmile Model No. FTB-16A-1 can connect the drop cable with feeder cable as the termination point in the FTTx network, which is able to meet at least 12 users connection. It support splicing, splitting, storage and management with suitable space.

Technical features:

  • Be made of high quality and lightweight ABS material
  • Support 1pc 1:8 cassette PLC installation
  • Wall mounting or Pole mounting can be option
  • IP55 protection level
  • Operating temperature: -20°C ~ +70°C; storage: -40°C ~ +80°C

Technical specification

Result (click “Generate” to refresh) Copy to clipboard Preview

Mode OTB-08A Color Black/Grey
Dimension W210*L126*H50mm Weight 0.58 Kg
Material PC+ABS/ABS Splitter 1*1:8 cassette PLC
Splice tray 8C Max capacity 8C
Waterproof IP55 Installation mode Wall/Pole mounting

Packaging data

Mode FTB-08C-2
Inner carton size 210*271*100mm Outer carton size 525*370*555mm(10PCS)
Pallet size 1130*1050*120 Outer carton G.W 16KG
