Product feature
Structural optimization design, with the best fiber capacity;
The remaining length of the optical fiber is precisely controlled and the performance of the optical cable is stable;
Dry cable core blocks water, is low-carbon and environmentally friendly;
Innovative design of the sheath surface enhances air-blowing performance.
Good Aramid yarn has excellent tensile performance.
Fast delivery,200km ADSS cable regular production time of about 10 days
Can using glass yarn instead of aramid to anti-rodent
| Technical specification | |||||
|---|---|---|---|---|---|
| Number of fiber cores | 2 cores | 4 cores | 6 cores | 8 cores | 12 cores |
| Nominal outer diameter (mm) | 1.15 | 1.15 | 1.35 | 1.5 | 1.65 |
| Approximate weight (g/m) | 1 | 1 | 1.3 | 1.8 | 2.2 |
| Minimum bending radius (mm) | 50 | 50 | 60 | 80 | 80 |
| temperature range | Storage: -30℃ ~ +60℃ Operation: -30℃ ~ +60℃ Installation: -5℃ ~ +50℃ | ||||
| Cable life (estimate) | 25 Year | ||||
| Number of fiber cores | 2 cores | 4 cores | 6 cores | 8 cores | 12 cores |
| Air delivery equipment | PLUMETTAZ： UM25, ERICSSON： F, | ||||
| CATWAY： FBT-1.1 | |||||
| Pipe specifications | 5.0 / 3.5 mm (field microtube test: 32 m × 16 circles) | ||||
| Pipe flow pressure | 7bar / 10bar | ||||
| Typical air delivery length | 500m / 1000 m | 500m / 1000 m | 500m / 1000 m | 500m / 1000 m | 500m / 800 m |
| Typical air delivery time | 10 min / 18 min | 10 min / 18 min | 12 min / 18 min | 13 min / 18 min | 15 min / 20 min |
