Performance:
- Voltage Rating : 300V
- Temperature Rating : -20°C to +75ºC
Construction:
Conductor:
- Solid or Stranded Copper
Insulation:
- Polyethylene (PE)
Shield:
- Aluminum Foil, Tinned Copper Braid
Braiding:
- CCA (Copper Clad Aluminum), TCWB (Tinned Copper Wire Braid)
Sheath:
- PVC (Polyvinyl Chloride) or LSZH (Low Smoke Zero Halogen)
Sheath Colour :
- Black
- White
- Customized
Standard:
- ISO 9001:2015 Certified
Application:
- RG58 Coaxial Cable is widely used in applications requiring reliable signal transmission. Its versatility makes it suitable for various applications, including telecommunications, military communications, data transmission, and RF connections in electronic equipment.
Specification:
| Cable Type | RG58 Coaxial Cable |
| Conductor Material | Copper / Copper-Clad Steel (CCS) / Aluminum |
| Conductor Size | 20 AWG / 18 AWG / 16 AWG |
| Shielding Material | Aluminum Foil + Braided Shield |
| Shielding Coverage | 95% |
| Impedance | 50 Ohms |
| Nominal Capacitance | 30.8 pF/ft |
| Attenuation | 6.1 dB/100 ft at 1000 MHz |
| Velocity of Propagation | 66% |
| Return Loss | ≥ 23 dB |
| Operating Temperature | -40°C to +80°C |
| Insulation Material | Foam Polyethylene / Solid Polyethylene |
| Insulation Thickness | 0.093 inches |
| Jacket Material | PVC / Low Smoke Zero Halogen (LSZH) |
| Jacket Thickness | 0.035 inches |
| Brand | Customizable |
Packing & Delivery:
1、Packing by roll, drum, spool or customized;
2、Delivery by sea or air.
FAQ:
Q1: Are you manufacturer?
A1: Yes, we are the professional manufacturer of wire and cable for more than 10 years.
Q2: How about the delivery time?
A2: About 15 days based on different model. For some standard products, we may have stock and could delivery immediately.
Q3: Is customized solution available?
A3: Yes, we can provide different customized solution.
Q4: Can you provide OEM service?
A4: Yes.
